The RFID key card holder is used to store the key card and guarantees a high level of security and energy efficiency, as all electrical loads still turned on are switched off when the key card is removed, with an adjustable run-on time.

The new RFID key card holder (with update V 1.1) was developed for two applications:

  1. As a JUNG product, it is available for universal application.
  2. As an OEM product, it has been developed for different key card manufacturers.

The key card holder recognises various card types. Within the JUNG product range, the key card holder recognises cards according to the standards ISO/IEC 14443 and ISO/IEC15693. The product cannot differentiate between guest and employee cards.

As an OEM product, the key card holder is produced, for example, for Assa Abloy Hospitality. Here there are two different card types defined for use: on the one hand, the MIFARE Classic® card as commissioning and employee card. On the other, the MIFARE Ultralight® C card as guest card. Both cards meet the standards ISO/IEC 14443 and ISO/IEC 15693. Due to the programming by the OEM customer, the device can differentiate between card types. In addition, the Ultralight® C card type allows "payment by card". The software update of the key card holder to Version 1.1 also enables the higher current consumption caused by the larger data storage on the card.

At https://www.jung-group.com/en-DE/Service/Tools-Services/Hotelcard-Configurator-RFID/ you can change the lens colour and brightness as well as the run-on time of the second 1-way NO contact according to your personal requirements. Additionally, individual laser engraving is possible.

RFID key card holder

You can find information on material, colour and the different ranges here:
